7 Poles plug in terminal block connector 300V / 20A Black 12-16 AWG Brass M3 Screw

Name: 7 Poles plug in terminal block connector 300V 20A Black 1216 AWG Brass M3 Screw
Brand: SCED
Price: 0.281 USD

China 7 Poles plug in terminal block connector 300V / 20A Black 12-16 AWG Brass M3 Screw wholesale

Brand Name : SCED

Model Number : TR-3N-04

Certification : CE, UL, CUL, CQC and VDE etc.

Place of Origin : China

MOQ : 500 Piece/Pieces

Price : USD 0.281-0.569 Per Pc

Payment Terms : T/T, L/C

Supply Ability : 1000000 Pole/Poles per Month

Delivery Time : 5-20 Working Days

Packaging Details : Standard Master Carton Dimension: 341 x 273 x 198mm; Standard Inner box dimension: 168 x 134 x 47mm.

Pitch : 7.4mm

Wire Range : 12-16 AWG

Poles : 7 poles

Current : 20A

Voltage : 300V

Screw : M4

Torque : 4.4-5.3 lbf.in

Stripping Length : 5-6mm

Clamp Cage : Brass

Insulation Material : PC

Contact Now

7 Poles plug in terminal block connector 300V / 20A Black 12-16 AWG Brass M3 Screw

Detailed product Description:

Pitch 7.40mm, 300V 20A, 7P, Feed-Through Terminal Blocks

Wire Range: ■Right angle wire inlet; □Vertical wire inlet; □45 degree wire inlet

Levels: ■Single Level; □Double levels; □Triple levels

Standard color: Black.

Other colors also available, please refer to below How to Order and select the color you want.

How to order:

Applications:

Our products will be used on Communication, Automation, Rail Transportation, Power Supply, PCB, Frequency Converters, Server Site, Switch, Power Supply, Electric Lighting, Industry Control, Security, Medical Equipment and so on.

Parameter and Drawing Specifications:

UL Technical Data	B	C	D
Rated Voltage / Current V/A	300 / 20	300 / 20
Wire Range AWG	12-16	12-16
IEC Technical Data
Overvoltage Category	Ⅲ	Ⅲ	Ⅱ
Contamination Class	3	2	2
Rated Voltage / Current V/A	250 / 20	320 / 20	400 / 20
Rated Surge Voltage KV	4	4	4
Rated Connecting Capacity mm²	4
Material
Insulation Material / Inflammability Class	PC / UL94, V-0
Conduction Board / Plating
Clamp Cage / Plating	Brass / Nickel Plated
Screw / Plating	Steel / Zinc Plated
Other Data
Stripping Length mm	5-6
Screw / Torque / lbf.in	M3 / 4.4-5.3

Competitive Advantage:

Full range products for selection
Flexible to design the exact part per customers’ demand
Good quality and competitive price.
